ROTOR FX - Stainless Steel Gear Pumps Rotor Pump FX Series Stainless Steel Gear Pumps Catalog Specification and Application Feature
Usually use for transportation of non lubricant, causticity, sticking liquid, or the liquid with solid grain or thread, or for sanitary transportation. It can be used for liquid under the temperature of -20�C ~ 200�C, the visadity of 5-5000cst.
Application
Suitable for machinary, petroleum, chemistry, foodstuff, medicine, metallurgy, brewage.
Structure
The synchromous gear powered drive system and the liquid transmission rotrr are fixed in different pump cavity, so different and more suitable design can be applied to make up a credible system. Flow Rated 1 ~ 20 m�/h Pressure 0.33 ~ 1 Mpa Power 0.75 ~ 11 kw Liquid Temperature Type Rated Flow Pressure -20�C ~ +200�C [m�/h] [Mpa] FX-1A 1 0.6 ~ 1 Material FX-1.5A 1.5 0.6 ~ 1 Stainless Steel FX-2A 2 0.6 ~ 1 FX-3A 3 0.6 ~ 1 FX-4A 4 0.6 ~ 1 FX-5A 5 0.6 ~ 1 FX-6A 6 0.6 ~ 1 FX-7.5A 7.5 0.6 ~ 1 FX-10A 10 0.33 ~ 0.6 FX-12A 12 0.33 ~ 0.6 FX-15A 15 0.33 ~ 0.6 FX-20A 20 0.33 ~ 0.6
